Pressure gauge KFM

Pressure gauge KM

Pressure gauge KFM

SKU: HTC-KFM

Pressure gauge with capsule element to measure small over pressures of gaseous fluids, overload protection up to 10 times, zero adjustment, steel case, adjustment accuracy class 1,6; measuring range 0 - 600 mbar

View leaflet

Availability: Delivery time on request

€96.03
€96.03

Benefits

  • Best prices
  • Fast delivery
  • Advice from specialists
Credit card Visa
Credit card Mastercard
iDeal
Bank Transfer
Product Description

Details

This pressure gauge by Heattec is manufactured by AZ Intec GmbH

Applications

  • Low pressure gas systems
  • Suitable for fluid medium, gaseous or dry that does not corrode copper alloy.

Product features

  • Low pressure series
  • Copper alloy wetted parts & stainless steel case
  • Capsule pressure gauge

Design

EN837-3

Accuracy class

± 1.6% of span

Capsule Element

Material: copper alloy

Movement

Copper alloy, nickel-silver pinion gear and shaft.
Zero adjustment screw on dial

Dial

White aluminum with black lettering

Pointer

Black aluminum (zero adjust on dial. Must remove window to access)

Case

304 stainless steel with stainless steel bayonet ring

Weather Protection

Weather resistant (NEMA 3 / IP 54)

Window Gasket

Buna-N

Window

Flat instrument glass

Working Range

Steady: Full scale value
Fluctuating: 0.9 x full scale value

Operating Temperature

Ambient:   -4°F to 140°F (-20°C to 60°C)
Media:      max. 212°F (+100°C)
                 max. 176°F (+80°C) for 4” & 6" LBM

Temperature error

Additional error when temperature changes from reference temperature of 68°F (20°C) +0.6% of span for every 18°F (10°C) rising or falling.

Additional Information

Additional Information

Manufacturer AZIntec
Scale 100 mm
Connection G 1/2"B
Estimated delivery 1 week
Country of Manufacture Germany
