Gas Burner BG950 M 500-3200 kW MBVEF425 B01S30
Product Description
Details
The BG950 is a industrial burner, with a capacity up to 3.200 kW, for 2 stage our modulating operations. Available for natural gas, LPG and biogas. The BG950 is equipped with hinged flange and slow opening solenoid valve.
Gas connection can be left or right. Recommended for over- and under pressure boilers and other industrial applications. Industry standard components are used. Designed for easy maintenance. Energy saving.
When biogas is used, Heattec shall always be contacted.
| Model | Partcode | Capacity kW | Gas | Multibloc | Ball valve | P inlet |
| BG950 | 850000285602 | 500-3200 | LPG+ | MBVEF425B01S30 | 2" | 55 |
| Natural | +GF520/1 | 100 | ||||
| BG950 | 850000285602 | 500-3200 | LPG+ | MBC-1900-VEF-65 | 2½" | 40 |
| Natural | +GF40065/3 | 65 |
Additional Information
Additional Information
| Manufacturer | Bentone |
|---|---|
| Output / Capacity | 500-3200 kW |
| Connection voltage | 400V |
| Type of gas | Natural / LPG |
| Multibloc | MBVEF425 B01S30 |
| Controls | LFL |
| Ball valve | 2" |
| Inlet pressure (mbar) | 55 |
| Estimated delivery | 2-3 weeks |
